Cat.6 UTP Keystone Jack

1. Unshielded Keystone Jack. The products are used in the Equipment Rooms & Work area as

communication connectors of the intelligent Buildings.

2. The structure of the Keystone Jack is compact, that can make your work more easy

and fast. The original dust-free hats can prevent the cable to break off from the IDC ports.

3 .According with ISO/IEC 11801:2002 Class E & ANSI/TIA/EIA/568-B.2-1 CAT.6

standard.

4. According with T568A & T568B. The T568A & T568B labels are adhibited on the both

sides of the product to give a exact guide when a engineer punches the cables.

5. Connecting: RJ45 port for STP patch cord and the IDC port for STP horizontal cabling.

6. According with ROHS requirement.

7. Fit for Cat.6 Cabling systems, can also be used on Cat.5 and Cat.5e cabling systems.

Technique Characteristics:

1. Housing and other plastic parts' material: PC UL94V-0

2. 8 Pin of the RJ45 jack: Phosphor bronze with 50U golden cladding. Insertion

Dependability: 750 times.

3. IDC Clips: Tinned phosphor bronze pins. Fit for 22AWG/23AWG/24AWG Cables.

Punching Dependability: 250 times.

4. Punching Tools: Standard 110 Punching tool.
